Siemens SIMOCODE pro PCS 7

Parameter
A.4 Block parameter MMMeas
SIMOCODE pro PCS 7 Library V9.0
256 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Parameter
Data format
Default setting
Meaning
RdErr STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Error read record
RdAct BOOL FALSE 1 = Enable read record
LocalAct STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Motor in Local Operation Mode: Local Mode Indicator
OnAct STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
ON mode is active
OosAct STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Out of Service is active.
PZDOut23
WORD
0
Process value for basic type 1
PZDOut45
WORD
0
Process value for basic type 3 (PROFINET)
ThmMotMod STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Thermal Motor Model in %
PhaUnbal STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Phase unbalance in %
MotCosPhi STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Motor power factor in %
ImMax STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Max Motor Current in %/Is
CurrL1 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Phase current IL1 in %/Is
CurrL2 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Phase current IL2 in %/Is
CurrL3 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Phase current IL3 in %/ls
TripCurr STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Last trip current in %ls
