A.4 Block parameter MMMeas
SIMOCODE pro PCS 7 Library V9.0
258 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Parameter
Data format
Default setting
Meaning
AMIn3E STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Analog Input 3 Effective in mA
MaxTemp STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Max. temperature in Celsius
TMTemp1 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Temperature 1 in Celsius
TMTemp2 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Temperature 2 in Celsius
TMTemp3 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Temperature 3 in Celsius
EFltCurr STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Ground fault current in mA
ETrpCurr STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Last ground fault trip current in mA
ActPower STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Active power in KW
AppPower STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Apparent power in KVA
OS_PermOut
DWORD
16#FFFFFFFF
Operator Permission: Output for OS
OS_PermLog DWORD 16#FFFFFFFF Display of OS_Perm with settings changed by block algo-
rithm
Opst_Out
DWORD
16#00
Enabled operator stations
ST_Worst
BYTE
16#80
Worst signal status
Status1
DWORD
16#00000000
Status1 information
ErrorNum
INT
-1
Error number
MsgErr1
BOOL
FALSE
1 = Messaging Error Occurs
MsgStat1
WORD
16#00
ALARM_8P: Status Output
MsgAckn1
WORD
16#00
ALARM_8P: ACK_STATE Output
ReserveOut
WORD
16#00
Reserved
