Siemens SIMOCODE pro PCS 7

Parameter
A.5 Block parameter MMStat
SIMOCODE pro PCS 7 Library V9.0
262 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Block parameters
Data format
Default setting
Meaning
ExtVa104
ANY
–
External Value 4
ExtVa105 ANY – External Value 5
ExtVa106
ANY
–
External Value 6
ExtVa107 ANY – External Value 7
ExtVa108
ANY
–
External Value 8
ExtVa109
ANY
–
External Value 9
ExtVa110
ANY
–
External Value 10
OS_Perm STRUCT
• Bit 0: BOOL
• ...
• Bit 31: BOOL
–
• 1
• 1
• 1
Operator permissions
OpSt_In
DWORD
–
Enabled operator stations
Feature STRUCT
• Bit 0: BOOL
• ...
• Bit 31: BOOL
–
• 0
• 0
• 0
Status of various features
ReserveIn
WORD
16#00
Reserved
Output parameters
Table A- 17 Output parameter MMStat
Parameter
Data format
Default setting
Meaning
RackF_Act STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Rack Failure
ModF_Act STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Module Failure
GrpErr STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Group error is active
RdErr STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Error read record
WrErr STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Error write record
RdErrStat
WORD
16#00
Status of read record error
WrErrStat
WORD
16#00
Status of Write record error
