Siemens SIMOCODE pro PCS 7

Parameter
A.7 Block parameter MMRevDhl
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
275
Parameter
Data format
Default setting
Meaning
Monitor BOOL TRUE Feedback Monitor
0 = Monitor OFF
1 = Monitor ON
MonTiStatic REAL 3.0 Monitoring Time of Feedback [s]
MonTiDynamic
REAL
3.0
Monitoring time of feedback error after operation in [s]
MonTiDyStop
REAL
3.0
Monitoring time of feedback on stopping in control output
SwOverTi
REAL
0.0
Switch over time to Fast Forward / Fast Reverse [s]
IdleTime
REAL
5.0
Offdelay Monitoring Time On Change Direction [s]
PulseWidth
REAL
3.0
Control Output Start / Stop Pulse Width [s]
WarnTiMan
REAL
0.0
Warning Time Prior to Motor Start [s]
WarnTiAut
REAL
0.0
Warning Time Prior to Motor Start in AUTO mode in [s]
RapidStp
BOOL
0
1 = Motor Rapid Stop command
RstOp
BOOL
0
Operator Reset Signal
RstLi STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Linked Reset Signal
BypProt
BOOL
FALSE
Bypass Protection in Sim/Local Modes
Trip STRUCT
• Value: BOOL
• ST: BYTE
–
• 1
• 16#FF
0 = Motor Tripped Signal
1 = Motor Healthy State
Permit STRUCT
• Value: BOOL
• ST: BYTE
–
• 1
• 16#FF
0 = Not Allowed to Activate Motor
1 = Permit is OK
Perm_En BOOL TRUE 0 = Permit disabled
1 = Permit enabled
PermRev STRUCT
• Value: BOOL
• ST: BYTE
–
• 1
• 16#FF
0 = Not Allowed to Activate Motor
1 = Permit Rev/FastRev is OK
PermRevEn BOOL TRUE 0 = Permit Rev/FastRev disabled
1 = Permit Rev/FastRev enabled
Intlock STRUCT
• Value: BOOL
• ST: BYTE
–
• 1
• 16#FF
0 = Motor is Interlocked
1 = Motor is Not Interlocked
Intl_En BOOL TRUE 0 = Interlock disabled
1 = Interlock enabled
IntlRev STRUCT
• Value: BOOL
• ST: BYTE
-
• 1
• 16#FF
0 = Motor Rev/FastRev is Interlocked
1 = Motor Rev/FastRev is Not Interlocked
IntlRevEn BOOL TRUE 0 = Interlock Rev/FastRev disabled
1 = Interlock Rev/FastRev enabled
