NOTICE
Electrostatic discharge
Electronic modules contain components that can be destroyed by electrostatic discharge.
These modules can be easily destroyed if they are not handled properly.
• To protect your equipment against damage, follow the instructions given in the chapter ESD
Guidelines.
Motors with DRIVE-CLiQ interface have an internal Sensor Module. This Sensor Module includes
an electronic rating plate. This simpli󹪝es commissioning for the SINAMICS S110 / S120 drive
system, since all the motor parameters are set automatically.
5.1.2.3 Encoder connection for motors without DRIVE-CLiQ (12/17-pole)
Motors without DRIVE-CLiQ are connected using the 12 or 17-pin 󹪞ange socket by default.
See also
Incremental encoder HTL 1024 S/R or HTL 2048 S/R (Page163)
5.1.2.4 Encoder assignment as a function of maximum permissible speeds
The following tables show the possible assignments of encoders to the 1PH8 motor series as a
function of maximum permissible speeds.
Table 5-4 Encoder types for motors without DRIVE-CLiQ
Encoder type Without
encoder
AM2048
S/R
HTL1024
S/R
HTL2048
S/R
IC2048
S/R
IN512
S/R
IN256
S/R
9th data position A E H J M T C
Permissible
n
max
speeds
(encoder) in r/min
- 12,000 9000 4600 12,000 15,000 24,000
Motor version
and
bearing system
n
max
(motor)
r/min
      
1PH808□-1□□□□-
□□□2
10,000 ✓ ✓ ✓
2)
✓
4)
✓ - -
1PH808□-1□□□□-
□L□2
15,000 ✓ - - - ✓
3)
✓ ✓
1PH808□-1□□□□-
□M□2
20,000 ✓ - - - ✓
3)
✓
5)
✓
1PH808□-1□□□□-
□N□2
24,000 - - - - - - ✓
1PH808□-1□□□□-
□Q□2
5000 ✓ ✓ ✓ ✓
4)
✓ - -
Motor components and options
5.1Motor components
1PH8 SIMOTICS M main motors
160 Con󹪝guration Manual, 12/2022, A5E51895839A
