You can assign the SIMOTICS M‑1PH8 main motors to climate class 3K4 with the exception of
the environmental parameter "condensation". Condensation is not permissible.
The higher the last number in the climate class 3K☐, the greater the requirements of the
motor.
Table 3-3 Environmental conditions are based on climate class 3K4
Environmental parameter Unit 3K4 class
a) Low air temperature °C +5
b) High air temperature °C +40
c) Low relative humidity % 5
d) High relative humidity % 95
e) Low absolute humidity g/m
3
1
f) High absolute humidity g/m
3
29
g) Rate of temperature change
1)
°C/min 0.5
h) Low air pressure kPa 70
i) High air pressure kPa 106
j) Solar radiation
3)
W/m
2
700
k) Thermal radiation -
2)
l) Movement of the air m/s 1.0
m) Condensation - Not permissible
n) Wind-driven precipitation
(rain, snow, hail, etc.)
- -
o) Water (other than rain) -
2)
p) Formation of ice - -
1)
Averaged over a period of 5min
2)
See types of protection
3)
In Central Europe, the midday sun stands at 60 ° to 65 ° and, in ideal weather conditions, shines with an irradiance of approx.
700 watts/square meter. In winter, the angles are only 13 ° to 18 ° and, even at noon, the irradiance is only approx. 247 watts/
square meter.
You will nd additional data on the ambient conditions, such as ambient temperatures
or conditions for transport and storage of the motors, in the relevant chapters of this
documentation.
3.3 Derating factors
Derating for ambient/coolant temperature
Operation: T = -15°C bis +40°C (without restriction)
Under conditions other than those specied above (ambient temperature > 40 °C or installation
altitude > 1000 m above sea level), the permissible torque/power reduction must be considered
(see Chapter "Ambient/coolant temperature (Page67)")
Motor description
3.3Derating factors
1PH8 SIMOTICS M main motors
34 Conguration Manual, 12/2022, A5E51895839A
