Siemens SIMOTICS M-1PH8 Configuration Manual

Encoder systems, built-in
without
DRIVE-CLiQ interface
• Absolute encoder EnDat 2048S/R (AM2048 S/R encoder)
• Incremental encoder sin/cos 1 Vpp 2048 S/R with C and D tracks (en‐
coder IC2048S/R)
• Incremental encoder sin/cos 1 Vpp 512S/R without C and D tracks
(encoder IN512S/R)
• Incremental encoder sin/cos 1 Vpp 256S/R without C and D track
(encoder IN256S/R)
• Incremental encoder HTL 1024S/R (encoder HTL1024 S/R)
• Incremental encoder HTL 2048S/R (encoder HTL2048 S/R)
Encoder systems, built-in
with
DRIVE-CLiQ interface
• Absolute encoder 22bit singleturn + 12 bit multiturn (encoder
AM22DQ)
• Incremental encoder 22bit with commutation position (encoder
IC22DQ)
• Incremental encoder 20bit without commutation position (encod‐
erIN20DQ)
• Incremental encoder 19bit without commutation position (encod‐
erIN19DQ)
Connection Connector for signals or DRIVE-CLiQ interface
(mating connector not included in scope of supply)
SH 80 ... SH 132: Terminal box NDE top / power connector
SH 160 ... SH 280: Terminal box NDE top
Rating plate (adhesive label) 1x glued on the motor
1x supplied loose in the terminal box
Paint 󹪝nish Standard paint 󹪝nish anthracite RAL 7016
Options See Options and Selection and Ordering data
Approvals, in accordance with cURus
1) Radial eccentricity of the shaft end, coaxiality of the centering wheel and axial eccentricity of the mounting 󹪞ange with respect
to the axis of the shaft end.
2) Applicable for "Performance", "High Performance" and "Premium Performance" versions
3) Based on the design, the following motors have temperature class 155 (F):
1PH8107-1□F2
1PH8138-2
1PH8107-1□M2
1PH8164
1PH8166
1PH8168
SH = Shaft height
S/R = signals/revolution
DE = Drive End (motor drive side; A side of the motor)
NDE = Non Drive End (motor fan side; B side of the motor)
3.2.3 Classifying environmental conditions according to climate classes
You can classify the environmental conditions for stationary use at weather-protected locations
according to standard DIN IEC 60721‑3‑3. The environmental parameters and their limit values
are de󹪝ned in various classes in this standard.
Motor description
3.2Technical characteristics and environmental conditions
1PH8 SIMOTICS M main motors
Con󹪝guration Manual, 12/2022, A5E51895839A 33
