• The type of construction IM V5 is only permissible with a protective roof (protection from
falling parts)
• Do not repaint/touch up explosion-proof motors. However, if this is required, then comply
with the following requirements:
– Limit the surface resistance of the paint used: Surface resistance ≤1GΩ for motors
belonging to device groupIII
– Breakdown voltage ≤4kV for device group III
Contact Technical Support (Chapter "Introduction") for the correct paint structure.
Note
For additional information, please contact Technical Support or your local sales partner.
5.2.4 Increased resistance to vibration (option L03)
Overview
1PH8 motors with shaft heights 180 and 225 and with the option L03 can be used in compliance
with certain operating conditions for applications with an increased vibration load. Possible
applications, for example on servo presses.
Design criteria for shaft heights 180 and 225
In conjunction with the option L03, the following motors can be selected:
1PH818x-1Ax00-xxx1-Z, Z=L03
1PH818x-1Ax10-xxx1-Z, Z=L03
1PH818x-1Ex00-xxx1-Z, Z=L03
1PH818x-1Ex10-xxx1-Z, Z=L03
1PH818x-1Hx00-xxx1-Z, Z=L03
1PH818x-1Hx10-xxx1-Z, Z=L03
1PH818x-1Jx00-xxx1-Z, Z=L03
1PH818x-1Jx10-xxx1-Z, Z=L03
1PH818x-1Mx00-xxx1-Z, Z=L03
1PH818x-1Mx10-xxx1-Z, Z=L03
1PH818x-2Ex00-xxx1-Z, Z=L03
1PH818x-2Ex10-xxx1-Z, Z=L03
1PH818x-2Mx00-xxx1-Z, Z=L03
1PH818x-2Mx10-xxx1-Z, Z=L03
1PH822x-1Ax00-xxx1-Z, Z=L03
Motor components and options
5.2Options
1PH8 SIMOTICS M main motors
178 Conguration Manual, 12/2022, A5E51895839A
