Siemens SIMOTICS M-1PH8 Configuration Manual

3.4.4 Article No. su󹪟xes for SH 180 to 280
Descriptions Data position of the order No.  
 1 2 3 4 5 6 7 - 8 9 10 11 12 - 13 14 15 16 - Z
 1 P H 8                
Shaft height 180 1 8
Shaft height 225 2 2
Shaft height 280 (only induction version and water
cooling)
2 8
Overall length (cannot be selected, determined by the choice of
rated power)
Induction version 1
Synchronous version 2
Encoder sys‐
tems
for motors with‐
out a
DRIVE-CLiQ in‐
terface
Without encoder
1)
A 2
Absolute encoder EnDat 2048S/R (encoder AM2048S/R) E 2
Incremental encoder HTL 1024 S/R (encoder HTL1024S/R)
1)
H 2
Incremental encoder HTL 2048S/R (encoder
HTL2048S/R)
1) 4)
J 2
Incremental encoder sin/cos1V
pp
2048S/R with C and D
track (encoder IC2048S/R)
M 2
Encoder sys‐
tems
for motors with
a
DRIVE-CLiQ in‐
terface
Absolute encoder 22 bit singleturn + 12 bit multiturn (en‐
coder AM22DQ)
F 1
Incremental encoder 22bit with commutation position
(encoder IC22DQ)
D 1
Winding version Rated speeds
(3 AC 380V to 480V)
400r/min, 500 r/min,
600 r/min, 700 r/min
B 
700 r/min, 800 r/min,
1000 r/min, 1100r/min
C
1000r/min, 1150 r/min,
1350 r/min, 1500r/min
D
1500r/min, 1750r/min,
2000r/min, 2200r/min
F
2500r/min, 2900r/min,
3200 (3400)r/min
L
Rated speeds
(3 AC 690V)
for shaft height 280
400r/min, 500r/min H
700r/min, 800r/min K
1000r/min, 1150r/min U
1500r/min, 1750r/min W
Cooling Forced ventilation, DE-->NDE (degree of protection IP 55) 0
Forced ventilation, NDE-->DE (degree of protection IP 55) 1
Water cooling (degree of protection IP 55) 2
Motor description
3.4Selection and ordering data
1PH8 SIMOTICS M main motors
44 Con󹪝guration Manual, 12/2022, A5E51895839A
