Siemens SIMOTICS M-1PH8 Configuration Manual

3.4.7 Article No. supplement for SH 132 and 160, synchronous-reluctance +
holding brake
Descriptions Data position of the order No.  
  1 2 3 4 5 6 7 - 8 9 10 11 12 - 13 14 15 16 - Z
 1 P H 8                
Shaft height 132 1 3
Shaft height 160 1 6
Overall length (cannot be selected, determined by the choice of
rated power)
Reluctance version E󹪟ciency with holding brake 6
Reluctance version Performance with holding brake 8
Encoder sys‐
tems
for motors
without a
DRIVE-CLiQ in‐
terface
Without encoder A 2
Absolute encoder EnDat 2048 S/R (encoder AM2048S/R) E 2
Incremental encoder HTL 1024 S/R (encoder HTL1024S/R) H 2
Incremental encoder HTL 2048 S/R (encoder HTL2048S/R) J 2
Incremental encoder sin/cos 1 V
pp
, 2048 S/R with C and D
track (encoder IC2048S/R)
M 2
Encoder sys‐
tems
for motors with
a
DRIVE-CLiQ in‐
terface
Absolute encoder, 22-bit singleturn + 12-bit multiturn (en‐
coder AM22DQ)
F 1
Incremental encoder, 22-bit, with commutation position
(encoder IC22DQ)
D 1
Winding ver‐
sion
Rated speeds
(3 AC 380 V to
480 V)
1000r/min, 1150r/min, 1350r/min,
1500r/min (only for forced ventilation)
D  
1500r/min, 1750r/min, 2000r/min,
2200r/min
F
2000r/min, 2300r/min, 2650r/min,
2800r/min
G
Cooling Forced ventila‐
tion DE -> NDE
(degree of protection IP 55) 0
Forced ventila‐
tion NDE -> DE
(degree of protection IP 55) 1
Water cooling (degree of protection IP 55) 2
Type of con‐
struction
IM B5 (IM V1, IM
V3)
(not possible for shaft height 160) 2
IM B35 (IM V15,
IM V35)
 3
Shaft exten‐
sion (DE)
Balancing 
Smooth shaft
(without key‐
way)
---  0
Fitted key Half-key  2
Bearings Vibration se‐
verity acc. to
Shaft and 
Motor description
3.4Selection and ordering data
1PH8 SIMOTICS M main motors
Con󹪝guration Manual, 12/2022, A5E51895839A 53
