Siemens SIMOTICS M-1PH8 Configuration Manual

3.4.1 Article No. su󹪟xes for shaft height 80 to 160
Descriptions Data position in Article No.
 1 2 3 4 5 6 7 - 8 9 10 11 12 - 13 14 15 16 - Z
 1 P H 8                
Shaft height 80 0 8
Shaft height 100 1 0
Shaft height 132 1 3
Shaft height 160 1 6
Overall length (cannot be selected, determined by the choice of
rated power)

Induction version 1
Synchronous version (only shaft height 132 and 160) 2
Encoder systems
for
Motors without a
DRIVE-CLiQ inter‐
face
Without encoder
1)
A 2
Absolute encoder EnDat 2048S/R (encoder
AM2048S/R)
2)
E 2
Incremental encoder HTL 1024S/R (encoder
HTL1024S/R)
1) 3)
H 2
Incremental encoder HTL 2048S/R (encoder
HTL2048S/R)
1) 4)
J 2
Incremental encoder sin/cos 1 V
pp
2048 S/R with C and D
tracks (encoder IC2048S/R)
2)
M 2
Incremental encoder sin/cos 1 V
pp
512 S/R without C and
D tracks (encoder IN512S/R)
1) 5) 10)
T 2
Incremental encoder sin/cos 1 V
pp
256 S/R without C and
D tracks (encoder IN256S/R)
1) 10)
C 2
Encoder systems
for
Motors with
DRIVE-CLiQ inter‐
faces
Absolute encoder 22-bit- singleturn + 12-bit multiturn
(encoder AM22DQ)
2)
F 1
Incremental encoder 22-bit with commutation position
(encoder IC22DQ)
2)
D 1
Incremental encoder 20bit without commutation posi‐
tion (encoder IN20DQ)
1) 5) 10)
U 1
Incremental encoder 19-bit without commutation posi‐
tion (encoder IN19DQ)
1) 10)
S 1
Winding version


Rated speeds (3 AC 380V to
480V)
400r/min, 500r/min,
600r/min, 700r/min
 B 
1000r/min, 1150r/min,
1350r/min, 1500r/min
D
1500r/min, 1750r/min,
2000r/min, 2200r/min
F
2000r/min, 2300r/min,
2650r/min, 2800r/min
G
2500r/min, 2800r/min,
3000r/min
L
3000r/min, 3300r/min,
3600r/min, 3900r/min
M
4500r/min, 5000r/min,
5500r/min, 6000r/min
N
Motor description
3.4Selection and ordering data
1PH8 SIMOTICS M main motors
Con󹪝guration Manual, 12/2022, A5E51895839A 37
