Cables
Mating connector: 6FX2003-0SU17
Table 5-13 Pre-fabricated cable for SINAMICS
6FX ☐ 002 - 2EQ10 - ☐☐☐ 0
↓
↓
5 MOTION-CON‐
NECTⓇ500
8 MOTION-CON‐
NECTⓇ800
↓↓↓
Length
Max. cable length 100 m
For other technical data and length code, refer to catalog, Chapter "MOTION-CONNECT
connection system"
5.2 Options
5.2.1 Overview of options
Chapter "Selection and ordering data (Page35)" contains an overview of which options are
available for which shaft heights.
5.2.2 Sealing air connection (option Q12)
Cooling lubricants containing oil capable of creepage, which can also be corrosive, are mainly
used for machine tools and transfer machines. For critical applications involving media with
extremely high creepage rates, generally degree of protection against water (according to EN
60034-5/IEC 60034-5) alone is not sucient. To address these particular applications, 1PH8
main motors can be ordered with sealing air connection by specifying option Q12. The sealing
air connection can be implemented both when using a terminal box and a power connector.
Note
Improved protection against oils and media that can creep
Sealing air does not increase the IP degree of protection against water. It does, however, improve
protection against oils and media that can creep.
Motor components and options
5.2Options
1PH8 SIMOTICS M main motors
Conguration Manual, 12/2022, A5E51895839A 169
