Note
This option is only permissible for motors without relubrication.
Note
Increase the pressure for "Premium Performance" bearing version
For the "Premium Performance" bearing version, you must increase the supply pressure to min.
2.0x10
5
Pa up to max. 5x10
5
Pa.
Conditioning: A Main drives without a shaft sealing ring
Min. inlet temperature (°C) Ambient temperature
Max. inlet temperature (°C) 40
Max. residual water content (g/m³) 0.12
Max. residual oil content (g/m³) 0.01
Max. residual dust (mg/m³) 0.1
Min. supply pressure (Pa) 2.0 x 10
5
Max. supply pressure (Pa) 3 x 10
5
Particle size for hollow shaft encoder (μm) <8
Particle size for optical encoders (µm) <3
Conditioning: B Main drives with a shaft sealing ring
Min. inlet temperature (°C) Ambient temperature
Max. inlet temperature (°C) 40
Max. residual water content (g/m³) 0.12
Max. residual oil content (g/m³) 0.01
Max. residual dust (mg/m³) 0.1
Min. supply pressure (Pa) 0.05 x 10
5
Max. supply pressure (Pa) 0.1 x 10
5
Particle size for hollow shaft encoder (μm) <8
Particle size for optical encoders (µm) <3
Motor components and options
5.2Options
1PH8 SIMOTICS M main motors
170 Con󹪝guration Manual, 12/2022, A5E51895839A
