The QR code on the China Energy Label includes a link to the listed motor folder.
Example: By clicking on the link http://elmm.bbqk.com/index.html?a=hb6zs (https://
ela.bbqk.com/index.html?uid=hb6zs), a folder opens with all of the listed 1PH8 motors, shaft
heights 180 and 225.
Note
The article number ① stated on the China Energy Label corresponds to the article number of the
basic motor type ② (boldface type) in the motor article number.
UKCA - United Kingdom Conformity Assessed
The SIMOTICS motor series satis󹪝es the conformity requirementsfor England, Wales and
Scotland.
3.2.2 Technical features
The technical features speci󹪝ed in the tables below refer to basic 1PH8 motors and are applicable
for induction, synchronous-reluctance and synchronous variants.
Depending on the electrical and mechanical con󹪝guration, it is possible to add options to the
basic model in order to adapt it to a speci󹪝c drive application (refer to Options, Selection and
Ordering data).
Table 3-1 Forced ventilation
Insulation of the stator winding
in accordance with EN 60034–1 (IEC 60034–1)
For an ambient temperature of up to 40°C
SH 80 to SH 280 temperature class 180 (H)
Cooling
in accordance with EN60034-6 (IEC60034-6)
Forced ventilation
SH 80 ... SH 225: Fan mounted axially at NDE
SH 280: Fan mounted radially at NDE
Temperature monitoring Temperature sensor in the stator winding
SH 180 ... SH 280: Additional temperature sensor as a standby
Fan supply voltage
(see "Technical data")
SH 80:
SH 100 ... SH 160:
SH 180...SH 225:
SH 280:
1 AC 230V 50/60Hz, 1 AC 265V 60Hz
3 AC 400V, 50/60 Hz, 3 AC 480V 60 Hz
1 AC 200V...277V, 50/60Hz (EC fan)
3 AC 380V ... 480V, 50/60Hz (EC fan)
Type
in accordance with EN60034-7 (IEC60034-7)
SH 80:
SH 100 ... SH 280:
IM B3, IM B5
IM B3, IM B5, IM B35
Degree of protection
in accordance with EN60034-5 (IEC60034-5)
SH 80 ... SH 280:
SH 180 ... SH 280:
IP55
IP23
Shaft extension at the drive
end (DE) in accordance with DIN 748-3 (IEC
60072-1)
Plain shaft or feather key
for full key or half-key balancing
Shaft and 󹪞ange accuracy
in accordance with DIN 42955 (IEC 60072-1)
1)
SH 80 ... SH 160
:SH 180 ... SH 280:
Tolerance R (reduced), SPECIAL
2)
Tolerance N (normal)
Vibration magnitudes
in accordance with Siemens / EN 60034-14 (IEC
60034-14)
SH 80...SH 160
SH 180 ... SH 280
Level R/A, SPECIAL/B
Level A
Motor description
3.2Technical characteristics and environmental conditions
1PH8 SIMOTICS M main motors
30 Con󹪝guration Manual, 12/2022, A5E51895839A
