China Energy Label
Name of the standard Minimum allowable values for energy e󹪟ciency and energy e󹪟ciency class of perma‐
nent-magnet synchronous motors (GB30253).
Date of entry into force July 1, 2020
A󹪜ected motors Permanent-magnet synchronous motors (without integrated brake) with a rated pow‐
er of 0.55 kW to 90 kW and a rated speed of 500 r/min to 3000 r/min controlled from
a converter with variable frequency on a line supply less than 1000V.
Motor requirements As of the implementation date of the guideline, all motors involved must have the
"China Energy Label".
A󹪜ected Siemens products The SIEMENS motors involved are subject to the requirements of Guideline GB30253.
Examples of the "China Energy Label" and the motor rating plate:
China Energy Label
1
Figure3-1 ① Article number(diagram showing a typical 1PH8)
Motor rating plate
The speci󹪝ed "1PH8184-2DD0" motor only serves as representative of the 1PH8 motor list.
This explanation is provided to the left of the Chinese title (speci󹪝ed for Chinese custom
authorities).
2
3
Figure3-2 ② Article number of the basic motor type (example for a 1PH8)
The permissible motor list can then be called using button ③ at the bottom right.
Motor description
3.2Technical characteristics and environmental conditions
