3.4.5 Article No. su󹪟xes for SH 280
Descriptions Data position of the order No.  
  1 2 3 4 5 6 7 - 8 9 10 11 12 - 13 14 15 16 - Z
 1 P H 8                
Shaft height 280 (forced ventilation and open-cir‐
cuit ventilation)
2 8
Overall length (cannot be selected, determined by the choice of
rated power)
Induction version 1
Encoder sys‐
tems
for motors
without a
DRIVE-CLiQ in‐
terface
Without encoder A 2
Absolute encoder EnDat 2048 S/R (encoder AM2048S/R) E 2
Incremental encoder HTL 1024 S/R (encoder HTL1024S/R) H 2
Incremental encoder HTL 2048 S/R (encoder HTL2048S/R) J 2
Incremental encoder sin/cos 1 V
pp
, 2048 S/R with C and D
track (encoder IC2048S/R)
M 2
Encoder sys‐
tems
for motors with
a
DRIVE-CLiQ in‐
terface
Absolute encoder, 22-bit singleturn + 12-bit multiturn (en‐
coder AM22DQ)
F 1
Incremental encoder, 22-bit, with commutation position
(encoder IC22DQ)
D 1
External encod‐
er systems
Incremental encoder HTL 1024 S/R POG 22 (Baumer-Hüb‐
ner), prepared for mounting
1)
G 
Incremental encoder HTL 1024 S/R POG 10 (Baumer-Hüb‐
ner), prepared for mounting
2)
K
Winding ver‐
sion
Rated speeds
(3 AC 380 V to
480 V)
400r/min, 500r/min, 600r/min, 700r/min B
700 r/min, 800 r/min, 1000 r/min, 1100 r/min C
1000r/min, 1150r/min, 1350r/min,
1500r/min
D
1500r/min, 1750r/min, 2000r/min,
2200r/min
F
Rated speeds
(690 V 3 AC)
400r/min, 500r/min H
700r/min, 800r/min K
1000r/min, 1150r/min U
1500r/min, 1750r/min W
Cooling Forced ventila‐
tion
(degree of protection IP 55) 1
Forced ventila‐
tion
(open-circuit ventilation with degree of protection
IP 23)
4
Type of con‐
struction
IM B3 (IM V6) 0
IM V5
6)
1
IM B5 with A660 󹪞ange (IM V3)
6)
2
IM B35 with A660 󹪞ange (IM V35) 3
IM V15 with A660 󹪞ange 5
Motor description
3.4Selection and ordering data
1PH8 SIMOTICS M main motors
Con󹪝guration Manual, 12/2022, A5E51895839A 47
