Descriptions Data position of the order No.
1 2 3 4 5 6 7 - 8 9 10 11 12 - 13 14 15 16 - Z
Shaft exten‐
sion (DE)
Balancing
Smooth shaft
(without key‐
way)
--- 0
Fitted key Full-key 1
Fitted key Half-key 2
Bearings Vibration se‐
verity acc. to
Siemens/EN
60034-14
Shaft and
ange accuracy
Standard A N A
Standard R/A R B
Increased radial
forces
A N E
Increased radial
forces
R/A R F
Power connec‐
tion
Cable entry Signal connec‐
tion
External fan
Terminal box
NDE right
Bottom DE
U
NDE top, air inlet from NDE, air-ow direction NDE-->DE ---
NDE left, air inlet from NDE, air-ow direction NDE-->DE G00
Terminal box
NDE left
Bottom DE V
NDE top, air inlet from NDE, air-ow direction NDE-->DE ---
NDE right, air inlet from NDE, air-ow direction NDE-->DE G02
Terminal box
NDE top
Right DE
W
NDE left, air inlet from NDE, air-ow direction NDE-->DE G00
NDE right, air inlet from NDE, air-ow direction NDE-->DE G02
Terminal box DE
top
4)
Right
NDE
X
NDE top, air inlet from NDE, air-ow direction NDE-->DE
4) 5)
---
NDE left, air inlet from NDE, air-ow direction NDE-->DE
4)
G00
NDE right, air inlet from NDE, air-ow direction NDE-->DE
4)
G02
Version
Without a DRIVE-CLiQ interface, PT1000 temperature sensor in the stator winding 2
With a DRIVE-CLiQ interface 1
For other versions, see options Z
1) When ordering, also select option H75
2) When ordering, also select options H56 or G80
4) Only possible if 12th data position is "0" (IM B3) and "1" (IM V5).
5) Only possible for assignments with terminal box 1XB7712-P..
6) Only possible if 14th data position is "A" and "B" (standard bearings); n
max
limited to 2000r/min
7) Only possible for the following combinations:
12th data position is "0" or "1" if 15th data position is "W" or "X"
Motor description
3.4Selection and ordering data
1PH8 SIMOTICS M main motors
48 Conguration Manual, 12/2022, A5E51895839A
