4.1 Cooling
4.1.1 General
The following table shows an overview of the available variants of cooling system.
Table 4-1 Cooling system variants of 1PH8 motors
Shaft height Motor type Forced ventilation Water cooling
80 Induction ⇓ ⇓
100 Induction ⇓ ⇓
132 Induction, synchronous-reluc‐
tance and synchronous
⇓ ⇓
160 Induction, synchronous-reluc‐
tance and synchronous
⇓ ⇓
180 Induction and synchronous ⇓ ⇓
225 Induction and synchronous ⇓ ⇓
280 Induction ⇓ ⇓
4.1.2 Forced ventilation
When mounting the forced ventilated motor, make sure the motor is well ventilated. Good
ventilation is especially important for encapsulated installation. Avoid warm exhaust air being
drawn in again. The cooling air must ow in and out without restriction. Avoid accumulated dirt
in the cooling ducts as this can reduce the cooling air ow.
All catalog data refer to an ambient temperature of 40°C and an installation altitude up to
1000m above sea level.
NOTICE
Thermal damage to temperature-sensitive parts
The motors can have surface temperatures of over +100°C. Temperature-sensitive parts in
contact with the motor or attached to the motor can be damaged. Temperature-sensitive parts
include cables and electronic components, for example.
• Never attach temperature-sensitive parts to the motor.
• Ensure that no temperature-sensitive parts are in contact with the motor.
1PH8 SIMOTICS M main motors
Conguration Manual, 12/2022, A5E51895839A 67
