Siemens SIMOTICS M-1PH8 - Incremental Encoder HTL 1024 S;R or HTL 2048 S;R

Encoder type AM22DQ IC22DQ IN20DQ IN19DQ
9th data position F D U S
Permissible n
max
speeds (encoder) in r/min 12,000 12,000 15,000 24,000
Motor version and bearing system n
max
(motor)
r/min
   
1PH813□-2□□□□-□□□1 4500 ✓ ✓ - -
1PH813□-5□□□□-□□□1 6500 ✓ ✓ - -
1PH813□-7□□□□-□□□1 6500 ✓ ✓ - -
1PH816□-1□□□□-□□□1 6500 ✓ ✓ - -
1PH816□-1□□□□-□L□1 9000 ✓ ✓ ✓ ✓
1PH816□-1□□□□-□M□1 10,000 - ✓ ✓ ✓
1PH816□-1□□□□-□Q□1 4000 ✓ ✓ - -
1PH816□-2□□□□-□□□1 4000 ✓ ✓ - -
1PH816□-5□□□□-□□□1 5000 ✓ ✓ - -
1PH816□-7□□□□-□□□1 5000 ✓ ✓ - -
1PH818□-1□□□□-□□□1 5000 ✓ ✓ - -
1PH818□-1□□□□-□L□1 7500 ✓ ✓ - -
1PH818□-2□□□□-□□□1 3800 ✓ ✓ - -
1PH822□-1□□□□-□□□1 4500 ✓ ✓ - -
1PH822□-1□□□□-□L□1 6000 ✓ ✓ - -
1PH822□-2□□□□-□□□1 3500 ✓ ✓ - -
1PH828□-1□□□□-□□□1 3300 ✓ ✓ - -
✓ Assignment possible
3) Motor/encoder assignment limited to 12,000 r/min
5) Motor/encoder assignment limited to 15,000 r/min
5.1.2.5 Incremental encoder HTL 1024 S/R or HTL 2048 S/R
Function
• Speed actual value sensing
• Indirect incremental measuring system for the position control loop
• One zero pulse (reference mark) per revolution
Table 5-6 Properties and technical data
Properties Incremental encoder HTL
Coupling at the NDE
• with SH 80 to 225: Integrated in the motor
• with SH 280: Built on to the motor
Operating voltage +10 ... +30V
Current consumption max. 150 mA
Incremental resolution
(periods per revolution)
1024 S/R or 2048 S/R
Motor components and options
5.1Motor components
1PH8 SIMOTICS M main motors
Con󹪝guration Manual, 12/2022, A5E51895839A 163
