Siemens SIMOTICS M-1PH8 Configuration Manual

3.4.3 Article No. supplements for SH 132 and 160, synchronous-reluctance
Descriptions Data position of the order No.
 1 2 3 4 5 6 7 - 8 9 10 11 12 - 13 14 15 16 - Z
 1 P H 8                
Shaft height 132 1 3
Shaft height 160 1 6
Overall length (cannot be selected, determined by the choice of
rated power)
Reluctance version E󹪟ciency 5
Reluctance version Performance 7
Encoder sys‐
tems
for motors with‐
out a
DRIVE-CLiQ in‐
terface
Without encoder A 2
Absolute encoder EnDat 2048S/R (encoder AM2048S/R) E 2
Incremental encoder HTL 1024 S/R (encoder HTL1024S/R) H 2
Incremental encoder HTL 2048 S/R (encoder HTL2048S/R) J 2
Incremental encoder sin/cos1V
pp
2048S/R with C and D
track (encoder IC2048S/R)
M 2
Encoder sys‐
tems
for motors with
a
DRIVE-CLiQ in‐
terface
Absolute encoder 22 bit singleturn + 12 bit multiturn (en‐
coder AM22DQ)
F 1
Incremental encoder 22bit with commutation position
(encoder IC22DQ)
D 1
Winding version Rated speeds
(3 AC 380V to 480V)
1000r/min, 1150r/min,
1350 r/min, 1500 r/min (only
for forced ventilation)
D 
1500r/min, 1750r/min,
2000r/min, 2200r/min
F
2000r/min, 2300r/min,
2650r/min, 2800r/min
G
Cooling Forced ventilation, DE-->NDE (degree of protection IP 55) 0
Forced ventilation, NDE-->DE (degree of protection IP 55) 1
Water cooling (degree of protection IP 65) 2
Type of con‐
struction
IM B3 (IM V5, IM V6, IM B6, IM B7, IM B8) 0
 IM B5 (IM V1, IM V3) 2
 IM B35 (IM V15, IM V35) 3
Shaft extension
(DE)
Balancing 
Plain shaft ---  0
Fitted key Full-key  1
Fitted key Half-key  2
Motor description
3.4Selection and ordering data
1PH8 SIMOTICS M main motors
42 Con󹪝guration Manual, 12/2022, A5E51895839A
