Descriptions Data position in Article No.
1 2 3 4 5 6 7 - 8 9 10 11 12 - 13 14 15 16 - Z
Top Left DE B
Top NDE Left C
Top DE Left D
Power connec‐
tor
Cable entry Signal connec‐
tion
(looking onto DE)
Top Right DE E
Top Left DE F
Top NDE Left G
Top DE Left H
Version
Without a DRIVE-CLiQ interface, PT1000 temperature sensor in the stator winding 2
With a DRIVE-CLiQ interface 1
Options for SH 80 Premium Performance:
Prepared for bearingless rotary unions Y64
Sealing air connection Q12
Flange for design IM B5 with 4 x M8 threaded holes Q52
1) Shaft end 24mm x 50mm (d x l)
2) Only possible in combination with option Y64.
3) For cooling the greased bearing (to lengthen bearing replacement intervals) and to protect against penetrating liquid, Option
Q12 (sealing air connection) is recommended for the Premium Performance version.
Motor description
3.4Selection and ordering data
1PH8 SIMOTICS M main motors
Conguration Manual, 12/2022, A5E51895839A 41
