Descriptions Data position of the order No.
1 2 3 4 5 6 7 - 8 9 10 11 12 - 13 14 15 16 - Z
Terminal box
(top)
Right DE A
Terminal box
(top)
Left DE B
Terminal box
(top)
NDE Right C
Terminal box
(top)
DE Right D
Version
Without a DRIVE-CLiQ interface, PT1000 temperature sensor in the stator winding 2
With a DRIVE-CLiQ interface 1
Brake versions:
Brake supply voltage
230 V 1 AC, 50/60 Hz
Holding brake DE with microswitch and manual brake release lever U63
Z options that cannot be combined with holding brake DE: K18, K90, L03, V92, M39
1) A U option must also be stated in the order to specify the holding brake version.
Shaft height 180: limited to n
max
= 3500r/min
Shaft height 225: limited to n
max
= 3100r/min
2) Only possible if 8th data position is "3" (induction version)
3) A holding brake can only be connected via a brake terminal box (top).
3.4.9 Options
Order
code
Option description For use with motors
"✓" = Option possible,
"---" = Option not possible
When ordering a motor with options, add a -Z to the order
number.
Specify the order code for every option required. For order
codes, avoid repeating the order codes in text form in the or‐
der.
Shaft height
80 to 160
Shaft height
180 to 280
Shaft height
280
For forced
ventilation
only
(11th data
position is "1"
or "4")
A12 Additional PTC thermistor circuit for alarm and trip (only possible
for version with terminal box)
✓ ✓ ✓
A25 Additional temperature sensor as reserve connected to signal ter‐
minal strip
(only possible for version with terminal box)
✓ Standard Standard
A72 2 PT100 resistance thermometers for bearing temperature moni‐
toring (DE and NDE)
--- ✓ ✓
B02 Factory test certicate in accordance with EN 10204 2.3 (for motor
ordered)
✓ Standard Standard
Motor description
3.4Selection and ordering data
1PH8 SIMOTICS M main motors
56 Conguration Manual, 12/2022, A5E51895839A
