Order
code
Option description For use with motors
"✓" = Option possible,
"---" = Option not possible
 When ordering a motor with options, add a -Z to the order
number.
Specify the order code for every option required. For order
codes, avoid repeating the order codes in text form in the or‐
der.
Shaft height
80 to 160
Shaft height
180 to 280
Shaft height
280
For forced
ventilation
only
(11th data
position is "1"
or "4")
B35 Factory test certi󹪝cate for vibration log ✓ ✓
5)
✓
5)
B36 Factory test certi󹪝cate for run-out log ✓ Only for SH
180
and SH 225
---
G00 External fan NDE left, air inlet at NDE
(possible if 15th data position is U, W, or X)
--- --- ✓
G02 External fan NDE right, air inlet at NDE
(possible if 15th data position is V, W, or X)
--- --- ✓
G06 External fan DE left, air inlet NDE
(possible if 11th position =1 and 15th position = U, V, or W; pos‐
sible if 11th position =4 and 15th position = W)
--- --- ✓
G07 External fan DE left, air inlet DE
(possible if 11th position =1 and 15th position = U, V, or W; pos‐
sible if 11th position =4 and 15th position = W)
--- --- ✓
G08 External fan DE right, air inlet NDE
(possible if 11th position =1 and 15th position = U, V, or W; pos‐
sible if 11th position =4 and 15th position = W)
--- --- ✓
G09 External fan DE right, air inlet DE
(possible if 11th position =1 and 15th position = U, V, or W; pos‐
sible if 11th position =4 and 15th position = W)
--- --- ✓
G11 External fan DE top, air inlet DE
(possible if 11th position =1 and 15th position = U, V, or W; pos‐
sible if 11th position =4 and 15th position = W)
--- --- ✓
G14 With external fan (only possible if 11th data position is "1" or "4") Only for SH
132
and SH 160
✓ ✓
G50 Nipple for SPM, with M8 adapter --- ✓ ✓
G80 Mounting of a POG 10 incremental encoder supplied by customer
(possible if 9th data position is "K")
--- --- ✓
H56 Mounting an incremental encoder POG 10 D 1024 (encoder
HTL1024S/R)
(possible if the 9th data position is "K")
--- --- ✓
H75 Mounting of a hollow shaft encoder HOG 22
supplied by the customer (possible if the 9th data position is "G")
--- --- ✓
K08 Encoder connection or DRIVE-CLiQ mounted on the opposite side
(not possible if 15th data position is "X")
--- ✓ ✓
Motor description
3.4Selection and ordering data
1PH8 SIMOTICS M main motors
Con󹪝guration Manual, 12/2022, A5E51895839A 57
