Siemens SIMOTICS M-1PH8 Configuration Manual

Order
code
Option description For use with motors
"✓" = Option possible,
"---" = Option not possible
 When ordering a motor with options, add a -Z to the order
number.
Specify the order code for every option required. For order
codes, avoid repeating the order codes in text form in the or‐
der.
Shaft height
80 to 160
Shaft height
180 to 280
Shaft height
280
For forced
ventilation
only
(11th data
position is "1"
or "4")
K09 Terminal box or power connector NDE right Only for SH
100
1)
to SH 160
--- ---
Terminal box NDE right, cable entry DE, signal connection top
(possible if the 15th data position is "A")
--- ✓ ---
K10 Terminal box or power connector NDE left Only for SH
100
1)
to SH 160
--- ---
Terminal box NDE left, cable entry DE, signal connection top (pos‐
sible if the 15th data position is "A")
--- ✓ ---
K16 Second shaft extension (d x l: 95mm x 170mm)
(possible if the 9th data position is "A" or "G" and 12th data position
is "0" or "3")
--- --- ✓
K17 Labyrinth seal DE for Performance version (14th data position "L") --- Only for SH
180
---
K18 Radial shaft sealing ring DE
2)
✓ ✓ ---
K40 Regreasing system, DE and NDE --- Only for SH
180
and SH 225
Standard
K45 AC 230V anti-condensation heating --- ✓ ✓
K69 Prepared for pipe connection NDE right (only possible for forced
ventilation, not for G00 to G11)
--- --- ✓
K70 Prepared for pipe connection NDE left (only possible for forced
ventilation, not for G00 to G11)
--- --- ✓
K71 Prepared for pipe connection NDE top (only possible for forced
ventilation, not for G00 to G11)
--- --- ✓
K80 Axial pipe connection NDE (only possible with forced ventilation) --- Only for SH
180
and SH 225
Options K69,
K70, K71
K83 Rotation of the terminal box through +90 degrees (possible in
combination with option K09 or K10 or if the 15th data position is
"U", "V" or "W")
--- ✓
4)
✓
K84 Rotation of the terminal box through -90 degrees (possible in
combination with option K09 or K10 or if the 15th data position is
"U", "V", "W" or "X")
--- ✓
4)
✓
K85 Rotation of the terminal box through +180 degrees (possible in
combination with option K09 or K10 or if the 15th data position is
"U", "V", "W" or "X")
--- ✓ ✓
Motor description
3.4Selection and ordering data
1PH8 SIMOTICS M main motors
58 Con󹪝guration Manual, 12/2022, A5E51895839A
