Order
code
Option description For use with motors
"✓" = Option possible,
"---" = Option not possible
When ordering a motor with options, add a -Z to the order
number.
Specify the order code for every option required. For order
codes, avoid repeating the order codes in text form in the or‐
der.
Shaft height
80 to 160
Shaft height
180 to 280
Shaft height
280
For forced
ventilation
only
(11th data
position is "1"
or "4")
K90 Version with ange size A400 (possible if 12th data position is "2",
"3" or "5")
--- Only for SH
180
---
L00 Replace terminal box (standard) with the next largest terminal box
(note dimension implications in the SPC)
--- ✓ ✓
L03 Increased resistance to vibration --- Only for SH
180
and SH 225
---
L12 Condensation drain hole --- Standard for
water cooling
Only if the
11th data po‐
sition is "1"
L27 NDE bearing in insulated version --- Only for SH
180
Standard
L29 Enhanced corrosion protection for installation in industrial/marine
climates
--- --- ✓
L72 Shaft made of special steel (note: option results in longer delivery
times)
--- --- ✓
L74 Fan version in IP65 degree of protection
3)
✓ --- ---
L76 EC fan 3 AC 400V 50/60Hz --- Only for SH
180
and SH 225
---
M03 Version for potentially explosive atmospheres Zone 2 Only for SH
100 to
SH 160
--- ---
M39 Version for potentially explosive atmospheres Zone 22 Only for SH
100 to
SH 160
Only for SH
180
and SH 225
---
M83 Additional back-o thread on motor feet (only possible if 12th data
position is "0" or "3")
--- --- ✓
P00 Undrilled cable entry plate --- ✓ Not for
1XB7820-P00
P01 Cable entry plate 3 x M63 x 1.5 --- Only for
1XB7700-P02
1XB7712-P03
Only for
1XB7712-P03
P02 Cable entry plate 3 x M75 x 1.5 --- Only for
1XB7712-P03
Only for
1XB7712-P01
1XB7712-P03
P03 Cable entry plate 4 x M75 x 1.5 --- --- Only for
1XB7712-P01
Motor description
3.4Selection and ordering data
1PH8 SIMOTICS M main motors
Conguration Manual, 12/2022, A5E51895839A 59
