Siemens SIMOTICS M-1PH8 Configuration Manual

Order
code
Option description For use with motors
"✓" = Option possible,
"---" = Option not possible
 When ordering a motor with options, add a -Z to the order
number.
Specify the order code for every option required. For order
codes, avoid repeating the order codes in text form in the or‐
der.
Shaft height
80 to 160
Shaft height
180 to 280
Shaft height
280
For forced
ventilation
only
(11th data
position is "1"
or "4")
P04 Cable entry plate 4 x M63 x 1.5 --- Only for
1XB7712-P03
Only for
1XB7712-P01
1XB7712-P03
Q00 Increase number of grounding terminals in the terminal box --- --- ✓
Q12 Sealing air connection ✓ --- ---
Q21 Screw locked with Loctite --- ✓ ⇓
Q25 Q25 fan connection NDE or at the top with M16x1.5 Only for SH
100 to
SH 160
--- ---
Q31 Metal nameplate instead of adhesive label ✓ ✓ ✓
Q52 Flange for design IM B5 with 4 x M8 threaded holes (only possible
when 14th data position is "N")
Only for SH 80 --- ---
Q81 Increased bearing preloading (only possible if the 14th data posi‐
tion "B", "C" and "D")
✓ --- ---
U60 230V holding brake ✓ --- ---
U61 230V holding brake with micro-switch ✓ --- ---
U62 230V holding brake with manual brake release lever ✓ --- ---
U63 230 V holding brake with micro-switch and manual brake release
lever
✓ Only for SH
180
and SH 225
---
U65 24VDC holding brake ✓ --- ---
U66 24VDC holding brake with microswitch ✓ --- ---
U67 24VDC holding brake with manual brake release lever ✓ --- ---
U68 24VDC holding brake with micro-switch and manual brake re‐
lease lever
✓ --- ---
V90 1PH7-compatible shaft extension (d x l: 42mm x 110mm)
(reduced radial forces must be observed; only possible if the 8th
data position is "1" or "3")
Only for SH
132
--- ---
V91 1FT6-compatible shaft extension (d x l: 48mm x 82mm)
(only possible for 8th data position is "2")
Only for SH
132
--- ---
V92 1PH7184-/1PL6184-compatible shaft extension (d x l: 60mm x
140mm)
(possible if the 8th data position is "1")
--- Only for
1PH8184
---
Y64 Hollow shaft prepared for bearingless rotary unions with 󹪞ange
diameter 114H6
✓ --- ---
Y82 Extra nameplate with customer speci󹪝cations (plain text required) --- ✓ ✓
Y84 Customer speci󹪝cations on nameplate (max. 30 characters) ✓ ✓ ✓
--- Paint 󹪝nish anthracite RAL 7016 Standard Standard Standard
Motor description
3.4Selection and ordering data
1PH8 SIMOTICS M main motors
60 Con󹪝guration Manual, 12/2022, A5E51895839A
