Siemens SIMOTICS M-1PH8 Configuration Manual

Order
code
Option description For use with motors
"✓" = Option possible,
"---" = Option not possible
 When ordering a motor with options, add a -Z to the order
number.
Specify the order code for every option required. For order
codes, avoid repeating the order codes in text form in the or‐
der.
Shaft height
80 to 160
Shaft height
180 to 280
Shaft height
280
For forced
ventilation
only
(11th data
position is "1"
or "4")
X01 Paint 󹪝nish in RAL 9005 (jet black) ✓ ✓ ✓
X02 Paint 󹪝nish in RAL 9001 (cream white) ✓ ✓ ✓
X03 Paint 󹪝nish in RAL 6011 (reseda green) ✓ ✓ ✓
X04 Paint 󹪝nish in RAL 7032 (pebble gray) ✓ ✓ ✓
X05 Paint 󹪝nish in RAL 5015 (sky blue) ✓ ✓ ✓
X06 Paint 󹪝nish in RAL 1015 (light ivory) ✓ ✓ ✓
X08 Paint 󹪝nish in RAL 9006 (white aluminum) ✓ ✓ ✓
X11 Paint 󹪝nish in RAL6019 (pastel green) ✓ ✓ ✓
X12 Paint 󹪝nish in RAL 5010 (gentian blue) ✓ ✓ ✓
X13 Paint 󹪝nish in RAL 5024 (pastel blue) ✓ ✓ ✓
X14 Paint 󹪝nish in RAL 5017 (tra󹪟c blue) ✓ ✓ ✓
X15 Paint 󹪝nish in RAL 9010 (pure white) ✓ ✓ ✓
X16 Paint 󹪝nish in RAL 6018 (yellow green) ✓ ✓ ✓
X17 Paint 󹪝nish in RAL 5014 (pigeon blue) ✓ ✓ ✓
X18 Paint 󹪝nish in RAL 9018 (papyrus white) ✓ ✓ ✓
X19 Paint 󹪝nish in RAL 2004 (pure orange) ✓ ✓ ✓
X20 Paint 󹪝nish in HWS (gray) ✓ ✓ ✓
X21 Paint 󹪝nish in RAL 9003 (signal white) ✓ ✓ ✓
X22 Paint 󹪝nish in RAL9002 (gray white) ✓ ✓ ✓
X23 Paint 󹪝nish in RAL 5005 (signal blue) ✓ ✓ ✓
X24 Paint 󹪝nish in RAL 7001 (sliver gray) ✓ ✓ ✓
X25 Paint 󹪝nish in RAL 1000 (green beige) ✓ ✓ ✓
X26 Paint 󹪝nish in RAL 6017 (May green) ✓ ✓ ✓
X27 Paint 󹪝nish in RAL 9023 (pearl dark gray) ✓ ✓ ✓
X28 Paint 󹪝nish in RAL 5009 (azure blue) ✓ ✓ ✓
X29 Paint 󹪝nish in RAL 7005 (mouse gray) ✓ ✓ ✓
X30 Paint 󹪝nish in RAL 1014 (ivory) ✓ ✓ ✓
X31 Paint 󹪝nish in RAL 5007 (brilliant blue) ✓ ✓ ✓
X44 Paint 󹪝nish in RAL 1023 (tra󹪟c yellow) ✓ ✓ ✓
X50 Paint 󹪝nish in RAL 3004 (purple red) ✓ ✓ ✓
X51 Paint 󹪝nish in RAL 2003 (pastel orange) ✓ ✓ ✓
X52 Paint 󹪝nish in RAL 3000 (󹪞ame red) ✓ ✓ ✓
X53 Paint 󹪝nish in RAL 7035 (light gray) ✓ ✓ ✓
X54 Paint 󹪝nish in RAL 7004 (signal gray) ✓ ✓ ✓
Motor description
3.4Selection and ordering data
1PH8 SIMOTICS M main motors
Con󹪝guration Manual, 12/2022, A5E51895839A 61
