Dimension drawings
10
10.1 SIEMENSProductCon󹪝gurator
The SIEMENS Product Con󹪝gurator supports you when con󹪝guring your drive.
You will 󹪝nd the following quickly and easily in the SIEMENS ProductCon󹪝gurator
• Technical data
• Characteristics
• dimension drawings
• 2D/3D CAD data
The SIEMENS ProductCon󹪝gurator supports you when creating system documentation
regarding project-speci󹪝c information.
Note
The 3D model in the SIEMENS Product Con󹪝gurator is a simpli󹪝ed representation that does not
show every detail.
You can 󹪝nd further information on the Internet at SIEMENSProductCon󹪝gurator
(www.siemens.com/SPC):
Recency of dimensional drawings
Note
Changing motor dimensions
Siemens reserves the right to change the dimensions of the motors as part of mechanical design
improvements without prior notice. This means that dimensional drawings can become out of
date.
You can request free of charge current dimension drawings from Technical Support or your
local sales partner.
1PH8 SIMOTICS M main motors
Con󹪝guration Manual, 12/2022, A5E51895839A 257
