Siemens SIMOTICS M-1PH8 Configuration Manual

3.4.6 Article No. supplement for shaft height 80 to 160 + holding brake DE
Descriptions Data position of the order No.  
  1 2 3 4 5 6 7 - 8 9 10 11 12 - 13 14 15 16 - Z
 1 P H 8                
Shaft height 80 0 8
Shaft height 100 1 0
Shaft height 132 1 3
Shaft height 160 1 6
Overall length (cannot be selected, determined by the choice of
rated power)
Induction version with holding brake
1)
3
Synchronous version with holding brake (only shaft heights 132 and
160)
1)
4
Encoder sys‐
tems
for motors
without a
DRIVE-CLiQ in‐
terface
without encoder
2)
A 2
Absolute encoder EnDat 2048 S/R (encoder AM2048S/R) E 2
Incremental encoder HTL 1024 S/R (encoder
HTL1024S/R)
2)
H 2
Incremental encoder HTL 2048 S/R (encoder
HTL2048S/R)
2)
J 2
Incremental encoder sin/cos 1 V
pp
, 2048 S/R with C and D
track (encoder IC2048S/R)
M 2
Encoder sys‐
tems
for motors with
a
DRIVE-CLiQ in‐
terface
Absolute encoder, 22-bit singleturn + 12-bit multiturn (en‐
coder AM22DQ)
F 1
Incremental encoder, 22-bit, with commutation position
(encoder IC22DQ)
D 1
Winding version 
Cooling Forced ventila‐
tion DE -> NDE
(degree of protection IP 55) 0
Forced ventila‐
tion NDE -> DE
(degree of protection IP 55) 1
Water cooling (degree of protection IP 55)
4)
2
Type of con‐
struction
IM B5 (IM V1, IM
V3)
5)
 2
IM B35 (IM V15,
IM V35)
8)
 3
Shaft exten‐
sion (DE)
Balancing 
Smooth shaft
(without key‐
way)
---  0
Fitted key Half-key  2
Bearings Vibration se‐
verity acc. to
Shaft and 
Motor description
3.4Selection and ordering data
1PH8 SIMOTICS M main motors
50 Con󹪝guration Manual, 12/2022, A5E51895839A
