Sound pressure level
in accordance with DIN EN ISO 1680, max.
tolerance +3dB, external fan 50Hz
SH 80 ... SH 132: 70 dB at a rated pulse frequency of 4 kHz and a
speed range up to 5000r/min
SH 160: 73 dB at a rated pulse frequency of 4 kHz and a
speed range up to 5000r/min
SH 180 and SH 225: 73 dB at a rated pulse frequency of 2 kHz and a
speed range:
Forced ventilation (IP55)
• SH180 to 5000r/min
• SH225 to 3500r/min
Open-circuit ventilation (IP23)
• SH180 to 3000r/min
• SH225 to 2000r/min
SH 280 74 dB at a rated pulse frequency of 2 kHz and a
speed range: up to 3300r/min
Forced ventilation (IP55)
• SH280 to 3300r/min
Open-circuit ventilation (IP23)
• SH280 to 2800r/min
Bearing versions and maximum speeds See Chapter "Mechanical properties of the motors"
Encoder systems, built-in
without
DRIVE-CLiQ interface
• Absolute encoder EnDat 2048S/R (AM2048 S/R encoder)
• Incremental encoder sin/cos 1 Vpp 2048 S/R with C and D tracks (en‐
coder IC2048S/R)
• Incremental encoder sin/cos 1 Vpp 512S/R without C and D tracks
(encoder IN512S/R)
• Incremental encoder sin/cos 1 Vpp 256S/R without C and D track
(encoder IN256S/R)
• Incremental encoder HTL 1024S/R (encoder HTL1024 S/R)
• Incremental encoder HTL 2048S/R (encoder HTL2048 S/R)
Encoder systems, built-in
with
DRIVE-CLiQ interface
• Absolute encoder 22bit singleturn + 12 bit multiturn (encoder
AM22DQ)
• Incremental encoder 22bit with commutation position (encoder
IC22DQ)
• Incremental encoder 20 bit without commutation position (encoder
IN20DQ)
• Incremental encoder 19 bit without commutation position (encoder
IN19DQ)
Connection Connector for signals or DRIVE-CLiQ interface
(mating connector not included in scope of supply)
SH 80 to SH 132: Terminal box NDE top / power connector
SH 160 to SH 225: Terminal box NDE top
SH 280: Terminal box NDE right
Rating plate (adhesive label) 1x glued on the motor
1x supplied loose in the terminal box
Paint 󹪝nish Standard paint 󹪝nish anthracite RAL 7016
Options See Options and Selection and Ordering data
Approvals, in accordance with cURus
Motor description
3.2Technical characteristics and environmental conditions
1PH8 SIMOTICS M main motors
Con󹪝guration Manual, 12/2022, A5E51895839A 31
