Siemens SIMOTICS M-1PH8 Configuration Manual

Descriptions Data position of the order No.  
  1 2 3 4 5 6 7 - 8 9 10 11 12 - 13 14 15 16 - Z
Siemens/EN
60034-14
󹪞ange accuracy
Standard A N  A
Power connec‐
tion
Cable entry Signal connec‐
tion
(looking onto DE)
Terminal box
(top)
Right DE  A
Terminal box
(top)
Left DE  B
Terminal box
(top)
NDE Left  C
Terminal box
(top)
1)
DE Left  D
Version 
With a DRIVE-CLiQ interface 1
Without a DRIVE-CLiQ interface, PT1000 temperature sensor in the stator winding 2
Special version (order codes are required for options) Z
1) Not possible for gk874 terminal boxes (1PH816 and 1PH8138-xxG2x)
Motor description
3.4Selection and ordering data
1PH8 SIMOTICS M main motors
54 Con󹪝guration Manual, 12/2022, A5E51895839A
