Siemens SIMOTICS M-1PH8 Configuration Manual

Brake connection (must be provided on the system side)
• Alternating voltage 230 VAC, 50 ... 60 Hz
• 24V DC up to shaft height 160
Ambient temperature
The brake module is designed for an ambient temperature of -5° C to +40° C. At temperatures
below -5° C and longer periods without power being applied to the brake, then it cannot
be excluded that the friction disk freezes. In this case, contact the manufacturer regarding
special measures that are required.
Note
Restricted maximum motor speed for a motor equipped with brake
The maximum speed of a motor with holding brake is limited to the maximum speed of the
holding brake (see n
max, Br
speed speci󹪝ed in the characteristic curves).
Note
Selection and ordering data
The selection and ordering data is contained in the chapter of the same name.
Note
No UL approval for the holding brakes for 1PH8, shaft heights 180 and 225
The holding brakes for motors, shaft heights 180 and 225 are not UL approved. As a
consequence, these motors with mounted brake do not have the cUR marking.
Technical data of the holding brakes
Table 5-15 Technical data of the mounted holding brake (DE) with emergency stop function
Shaft height 80 100 132 160 180 225
Motor type 1PH808□ 1PH810□ 1PH813□ 1PH816□ 1PH818□ 1PH822□
Brake type Size 13 Size 13 Size 13 Size 13 NFF-A 63 NFF-A 100
Holding torque
Nm
29 60...15 140...310 280...500 1000 1600
Maximum speed n
max
r/min
5000 5000 4500 4000 3500 3100
Moment of inertia J
B
kgm
2
0.00093 0.0048 0.0141 0.0266 0.022 0.051
Weight m
Br
kg
10 21 46 66 63 88
Coil current 230V AC
±10%
A
0.8 1.0 1.3 1.9 2.2 2.7
Motor components and options
5.2Options
1PH8 SIMOTICS M main motors
Con󹪝guration Manual, 12/2022, A5E51895839A 181
