Signal Cause Remedy
Complete information on the messages is available in the List Manual.
2002: Status of the delay timer SS1 in the two monitoring channels is
different.
Response to a discrepancy when STO is active (Page 226)
Response to a discrepancy when SS1 is active (Page 246)
2003: Status of the STO terminal at processor 1 and processor 2 is
different.
Remedy for 2000, 2001, and 2003:
● Check the F-DI changeover tolerance time. Increase the value
(p9650).
● Check the F-DI wiring (contact problems).
● Check the causes of the STO selection in r9772.
6000: Internal software fault
● Switch off the power supply voltage of the inverter and switch on
again.
● Upgrade firmware to later version
● Replace Control Unit
6064: Target address and PROFIsafe address differ (F_Dest_Add).
● Check the value of the F_Dest_Add F-parameter in the inverter
● Check the PROFIsafe address at processor 1 (p9610) and
processor 2 (p9810).
6065: Target address invalid (F_Dest_Add).
● The target address must not be 0 or FFFF.
6066: Source address invalid (F_Source_Add).
● The source address must not be 0 or FFFF.
6067: Watchdog time value invalid (F_WD_Time).
● The watchdog time value must not be 0.
6165: Fault in reception of the PROFIsafe telegram. This fault can also
occur if the inverter has received an inconsistent or out-of-date PRO‐
FIsafe telegram after the power supply voltage is switched off and
switched on again or after the PROFIBUS/PROFINET line has been
inserted.
● Check the configuration and communication in the inverter.
● Check the value of the F_WD_Time F-parameter in the inverter.
Increase the value.
6166: Time monitoring fault in reception of the PROFIsafe telegram.
● Check the configuration of the communication in the inverter.
● Check the setting of the F_WD_Time value in the inverter. Increase
the value.
● Evaluate the diagnostic information in the F host.
● Check the PROFIsafe connection.
A01620,
F01620
Safe torque off active Not necessary.
A01621,
F01621
Safe Stop 1 active Not necessary.
Operation
6.14 List of alarms and faults
Safety Integrated - SINAMICS G110M, G120, G120C, G120D and SIMATIC ET 200pro FC-2
322 Function Manual, 01/2017, FW V4.7 SP6, A5E34261271B AD

Siemens SINAMICS G120C Specifications

General

Communication Interfaces	PROFINET, PROFIBUS, USS, Modbus RTU
Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Storage Temperature	-40°C to +70°C
Power Range	0.55 kW to 132 kW
Voltage Range	380 V to 480 V
Output Voltage	0 V to Supply Voltage
Frequency Range	0 Hz to rated output frequency
Control Modes	Vector control with encoder
Protection	Overload, overvoltage, undervoltage, short circuit, ground fault
Relative Humidity	5% to 95%, non-condensing
Altitude	Up to 2000 m without derating
