5.3.2.6
Displaying the trace recording
Requirement
● An online connection has been established to the drive.
● A recorded trace is saved in the drive.
Or:
● A measurement is in the "Measurements" system folder.
Procedure
To display the recording, proceed as follows:
1. Select a trace in the drive.
2. Double-click the selected trace.
3. If required, activate the icon
for monitoring.
Or:
1. In the
"Measurements" system folder, select a measurement .
2. Double-click the selected measurement.
Result
The recording is displayed in the "Diagram" tab.
5.3.2.7
Saving measurements in the project
Requirement
● An online connection has been established to the drive.
● A recorded trace is saved in the drive.
● The data of the trace in the drive must of been displayed at least once in the curve
diagram. For display, the recorded data are loaded from the drive.
Procedure
To save a recording in the project, proceed as follows:
1. Open the trace in the drive with the recorded data (see Chapter "Creating or calling a
trace (Page 158)").
2. Ensure that the actual data from the drive are loaded by activating icon
.
3. After activating icon
wait until all data have been loaded and displayed.
