Diagnostics
5.3 Diagnostics via Startdrive
Commissioning with Startdrive
Commissioning Manual, (IH3), 07/2016, 6SL3097-4AA10-0BP0
167
5.3.2.9
Transferring the trace configuration from the drive to the project
Requirement
● An online connection has been established to the drive.
● A trace is saved in the drive.
Procedure
Proceed as follows to transfer a trace configuration to the project:
1. Open a trace in the drive (see Chapter "Creating or calling a trace (Page 158)").
2. If required, activate the icon
for monitoring.
3. Click on icon
to transfer the trace configuration from the drive into the project.
Result
The configuration is transferred as new trace configuration into the "Traces" system folder.
A trace configuration with the same name in the system folder is overwritten.
5.3.2.10
Deleting a trace configuration
Requirement
● An online connection has been established to the drive.
● A trace is saved in the drive.
Procedure
Proceed as follows to delete a trace configuration in the drive:
1. Open a trace configuration in the drive (see Chapter "Creating or calling a trace
(Page 158)").
2. If required, activate the icon
for monitoring.
3. Click on icon
to delete the selected trace configuration.
A confirmation prompt opens.
4. To confirm the deletion, in the query, click on "Yes".
Or
1. In the project navigation, select one or several trace configurations in the drive
/ .
2. Call the "Delete" shortcut menu to delete the trace configurations in the drive.
A confirmation prompt opens.
3. To confirm the deletion, in the query, click on "Yes".
