Commissioning
4.3 Creating a project
Commissioning with Startdrive
Commissioning Manual, (IH3), 07/2016, 6SL3097-4AA10-0BP0
71
Drawing the DRIVE-CLiQ connection
A DRIVE-CLiQ connection is drawn between two DRIVE-CLiQ ports.
1. Left-click the output port and keep the mouse button pressed.
Figure 4-16 Drawing the DRIVE-CLiQ connection
2. Drag the blue line displayed to the target port.
A connection is established between the two ports.
System rules, sampling times and DRIVE-CLiQ wiring (Page 205)
