Programming and Operating Manual (Milling)
6FC5398-4DP10-0BA6, 09/2017
21
5
Setting the user interface language
Note
The default user interface language is dependent on the PPU type. For a PPU with Chinese keys, the default language is
Chinese after power-
on; otherwise it's English. If you desire to change it, proceed through the following operating sequence;
otherwise, skip this chapter and proceed to the next chapter for setting up tools.
Operating sequence
+
1.
Select the system data operating area.
2.
Open the user interface language selection window.
3.
Use the cursor keys to select the desired language.
4.
Press this softkey to confirm your selection and the system is automatically r
estarted to
activate the selected language.
6
Setting up tools
6.1
Creating a tool
Note
The control system supports a maximum of 64 tools and 128 cutting edges. You can create a maximum of nine cutting
edges for each tool. Before executing a part program, you must first create the desired tool in the tool list and proceed wit
h
the tool setting operations.
Operating sequence
1.
Selec
t the offset operating area.
2.
Open the tool list w
indow.
3.
Open the lower
-level menu for tool type selection.
