Programming and Operating Manual (Milling)
6FC5398-4DP10-0BA6, 09/2017
281
â‘¥
Displays the defined user data "Setting user data (Page 64)"
⑦
Measures the tool manually or automatically • "Measuring the tool manually (Page 27)"
• "Measuring the tool with a probe (auto) (Page 56)"
⑧
Creates a new tool "Creating a tool (Page 21)"
⑨
Opens a lower-level menu for cutting edge settings "Creating/changing a cutting edge (Page 22)"
â‘©
Removes the currently selected tool from the tool list -
Searches for your desired tool with the tool number -
Program management operating area
Softkey functions
Pressing this key on the PPU allows you to open the following window:
Stores the NC programs for subsequent operations
Manages and transfers the manufacturer cycles
Reads in/out files via the USB drive and executes part programs from the external storage media
Reads in/out files via the Ethernet interface and executes part programs from a computer
Backs up manufacturer files
⑦
Shows the recently accessed files
Executes the selected file. No editing is allowed in the execution process.
Creates new files or directories
files
