Programming and Operating Manual (Milling)
66 6FC5398-4DP10-0BA6, 09/2017
Executing from external (through USB interface)
Prerequisite:
A USB memory stick (which includes the part program to be executed) is inserted in the front USB interface of
the PPU.
Proceed as follows to execute a part program from external through the USB interface:
ram management operating area.
y to enter the USB directory, and select the program file you desire to exe-
To directly execute the program, press this softkey. The system automatically switches to
"AUTO" mode in the machining operating area. The program is tran
sferred to the buffer
memory on the control system and then displayed
in the following window:
You can also press this key on the PPU to view the program blocks first before
executing.
Then press the following softkey to execute:
If desired, you can use this softkey to spe
cify how you want the program to be executed.
For more information of the program control, refer to Section "
Program control functions
53)" .
Press this key to execute the program. The program is reloaded continuously.
the program or after pressing this key, the program is automatically
removed from the control system.
Note
The USB directory is automatically identified if a USB stick is inserted.
Do not remove the USB stick during the external program execution throu
gh the USB interface.
