Programming and Operating Manual (Milling)
6FC5398-4DP10-0BA6, 09/2017
65
Configuring the operating area after startup
The machining operating area is displayed by default after the startup of the control system. Alternatively, you can select
another operating area which you desire to enter after the system starts up.
Select the system data operating area.
Open the window for setting the startup operating area through the following softkey oper
a-
Use the cursor keys to select the desired operating area in the following window:
Press this softkey to confirm your setting, and the configured operating system will display
after the control system restarts.
Executing/transferring a part program from external
You're recommended to use the Notepad editor with ANSI character encoding to create/edit part program files on the
computer. Program files in other encoding formats (for example, Unicode) may cause unexpected errors after being
imported into the control system.
Executing/transferring through the USB interface
The USB interface on the front of the PPU can be used to connect to a USB device, for example:
● An external USB memory stick, to transfer data between the USB stick and the control system
● An external USB keyboard which functions as an external NC keyboard
