Programming and Operating Manual (Milling)
6FC5398-4DP10-0BA6, 09/2017
235
The error text that is displayed together with the alarm number gives you more detailed information on the error cause.
Block preparation in the NC is aborted
62000 ... 62999 Clear key The block preparation is interrupted;
the cycle can be continued with the
following key after the alarm has been
cleared:
The error numbers are classified as follows:
6 _ X _ _
● X=0 General cycle alarms
● X=1 Alarms generated by the drilling, drilling pattern and milling cycles
The cycles display their messages in the message line of the control system. These messages do not interrupt the program
execution.
Messages provide information with regard to a certain behavior of the cycles and with regard to the progress of machining
and are usually kept beyond a machining step or until the end of the cycle. An example of messages is as follows:
"Depth: according to the value for the relative depth" from all drilling cycles.
Machining typical milling parts
13.1
Operations before programming
Operating sequence
1.
Turn on the power supply for the machine tool. Proceed with the operations for the refe
r-
ence point approach, if the machine axis is equipped with an incremental encoder (see
Chapter "
Switching on and referencing (Page 20)").
Create the required tools (see Section "Creating a tool (Page 21)").
Activate the tools and the spindle (see Section "Activating the tool and the spindle
(Page
23)").
4.
eel assignment operations if the machine manufacturer has not
assigned the handwheel for the control system (see Chapter "
Assigning the handwheel
24)").
5.
Proceed with the tool setting operations to finish measuring all the tools (see Section
"Measuring the tool manually (Page 27)").
6.
Verify the tool offset result to guarantee the safety and correctness of machining (see Se
c-
tion "Verifying the tool offset result (Page 28)").
