Siemens SINUMERIK 808D User Manual

Programming and Operating Manual (Milling)
234 6FC5398-4DP10-0BA6, 09/2017
12.6.12
High speed settings - CYCLE832
Programming
CYCLE832 (TOL, TOLM, 1)
Parameters
Parameter
Data type
Description
TOL
REAL
Tolerance of machining axes
TOLM INT Machining type selection
0: Deselect
1: Finishing
2: Semi-finishing
3: Roughing
PSYS
INT
Internal parameter, only the default value 1 is possible
Function
Use CYCLE832 to machine free-form surfaces that involve high requirements for velocity, precision and surface quality.
This cycle function groups together the important G codes, machine data and setting data that are required for high-speed
cutting machining.
Explanation of the parameters
TOL (Tolerance)
This refers to the tolerance of axes involved in machining. The tolerance value is written to the relevant machine or setting
data depending on the G codes.
TOLM (Machining types)
This parameter determines which technological machining type is to be used.
12.7
Error messages and error handling
12.7.1
General Information
If error conditions are detected in the cycles, an alarm is generated and the execution of the cycle is aborted.
Furthermore, the cycles display their messages in the message line of the control system. These messages do not interrupt
the program execution.
The errors with their reactions and the messages in the message line of the control system are described in conjunction with
the individual cycles.
12.7.2
Error handling in the cycles
If error conditions are detected in the cycles, an alarm is generated and the machining is aborted.
Alarms with numbers between 61000 and 62999 generated in the cycles. This range of numbers, in turn, is divided again
with regard to alarm responses and cancel criteria.
