11.03 3 Safety-Related Functions
3.5 Safely-reduced speed (SG)
© Siemens AG 2003 All Rights Reserved
SINUMERIK 840D/SIMODRIVE 611 digital SINUMERIK Safety Integrated (FBSI) - Edition 11.03
3-107
• The PLC SGEs for selecting gear ratios are described in
Chapter 4.3, "Interface signals".
• The motor encoder system is parameterized the same in the drive machine
data and in the NCK machine data.
• The example should be applicable for the 1st drive.
• Enabled SI function SBH/SG.
Table 3-35 Encoder data overview for 840D
Number Name
36910 $MA_SAFE_ENC_SEGMENT_NR
36911 $MA_SAFE_ENC_MODULE_NR
36912 $MA_SAFE_ENC_INPUT_NR
36915 $MA_SAFE_ENC_TYPE
36916 $MA_SAFE_ENC_IS_LINEAR
36917 $MA_SAFE_ENC_GRID_POINT_DIST
36918 $MA_SAFE_ENC_RESOL
36920 $MA_SAFE_ENC_GEAR_PITCH
36921 $MA_SAFE_ENC_GEAR_DENOM[n]
36922 $MA_SAFE_ENC_GEAR_NUMERA[n]
36925 $MA_SAFE_ENC_POLARITY
Note:
Data is described in Chapter 4, "Machine data for SINUMERIK 840D"
Table3-36 Encoder data overview for 611 digital
Number Name
1316 $MD_SAFE_ENC_CONFIG
1317 $MI_SAFE_ENC_GRID_POINT_DIST
1318 $MI_SAFE_ENC_RESOL
1320 $MI_SAFE_ENC_GEAR_PITCH
1321 $MI_SAFE_ENC_GEAR_DENOM[n]
1322 $MI_SAFE_ENC_GEAR_NUMERA[n]
Note:
Data is described in Chapter 4, "Machine data for SIMODRIVE 611digital"
• Definition of SGEs/SGAs in the NCK monitoring channel
– for 840D
Logical slot for the terminal block: 5
Slot number of the sub-module for SGEs: 3
I/O number for the signal "gear ratio selection bit 0": 1
I/O number for the signal "gear ratio selection bit 1": 2
Note
The SGEs/SGAs used in the NCK monitoring channel must also be supplied
by the machine manufacturer in the drive monitoring channel.
Parameter set changes via SGEs must be coupled to a parameter set change
in the NC.
