Procedure
Proceed as follows to load the configured hardware configuration into the SINUMERIK MC:
1. In the project navigation, select a device name, e.g. "PLC_1".
2. In shortcut menu, select "Load to device > Hardware configuration".
Note
Scope of the data to be loaded
Alternatively, you can select one of the other commands to load additional data to the
SINUMERIK MC in this operation.
See TIA Portal help, keyword "General information on downloading".
The "Extended download" dialog opens.
Figure 6-7 Extended download
Commissioning and configuring
6.4 Load the configuration into the control system
Safety Integrated (with SINAMICS S120)
Commissioning Manual, 02/2020, A5E46305916B AB 243
