10.6 Interface signals: Axis/spindle signals
10.6.1 Interface signals: Axis/spindle signals
As PLC user interface, certain axis-specific signals are mapped from the SIC/SCC (Page 212)
in the axis DB (Page 213):
● DB31 … DB38, Safety Info Channel (SIC)
● DB31 … DB38, Safety Control Channel (SCC)
This means, for example, that you can perform the brake test (Page 293) via the PLC user
program.
Further information
Additional information on the PLC user interface can be found in the
Function Manual SINUMERIK MC PLC (https://support.industry.siemens.com/cs/ww/en/view/
109767477).
Data descriptions
10.6 Interface signals: Axis/spindle signals
Safety Integrated (with SINAMICS S120)
Commissioning Manual, 02/2020, A5E46305916B AB 379
