Siemens SINUMERIK MC - SIC;SCC (Profidrive) Process Data; S_STW1 B: Safety Control Channel Control Word 1

Byte Bit Meaning Remarks
3 0 Position at cam 25 1 Position is at cam 25
0 Position is not at cam 25
1 Position at cam 26 1 Position is at cam 26
0 Position is not at cam 26
2 Position at cam 27 1 Position is at cam 27
0 Position is not at cam 27
3 Position at cam 28 1 Position is at cam 28
0 Position is not at cam 28
4 Position at cam 29 1 Position is at cam 29
0 Position is not at cam 29
5 Position at cam 30 1 Position is at cam 30
0 Position is not at cam 30
6 Safe Cam active 1 Safe Cam is active
0 Safe Cam is not active
7 Validity of the values of Safe Cam 1 Values of Safe Cam apply
0 Values of Safe Cam do not apply
10.5.3 SIC/SCC (PROFIdrive) process data
10.5.3.1 S_STW1B: Safety Control Channel control word 1
S_STW1B
Safety Control Channel control word 1
Table 10-19 Description of S_STW1B
Bit Meaning Remarks Parameter
0...7 Reserved – – –
8 Extended Functions test stop/forced
checking procedure
1 Extended Functions test stop/forced checking pro‐
cedure selected
r10251.8
0 Extended Functions test stop/forced checking pro‐
cedure deselected
9...15 Reserved – – –
Data descriptions
10.5 Process data
Safety Integrated (with SINAMICS S120)
