Siemens SINUMERIK MC - S_SLS_LIMIT_A: SLS Limit Value Input; S_SLS_LIMIT_A_ACTIVE: Active SLS Limit Value

Byte Bit Meaning Remarks
3 0 F-DI 0
2)
1 F-DI 0 inactive
0 F-DI 0 active
1 F-DI 1
2)
1 F-DI 1 inactive
0 F-DI 1 active
2 F-DI 2
2)
1 F-DI 2 inactive
0 F-DI 2 active
3 SS2ESR active 1 SS2ESR active
0 SS2ESR not active
4 SS2E active 1 SS2E active
0 SS2E not active
5 SOS selected 1 SOS selected
0 SOS deselected
6 SLP upper limit maintained 1 SLP: Upper limit maintained
0 SLP: Upper limit not maintained
– The status signal "upper SLP limit maintained"
always corresponds to the diagnostic signal "up‐
per SLP limit maintained" (r9722.30).
7 SLP lower limit maintained 1 SLP: Lower limit maintained
0 SLP: Lower limit not maintained
– The status signal "lower SLP limit maintained"
always corresponds to the diagnostic signal "low‐
er SLP limit maintained" (r9722.31).
1)
Signals not relevant for Extended Functions: Must not be evaluated.
2)
Only valid for CU310-2.
10.5.2.6 S_SLS_LIMIT_A: SLS limit value input
S_SLS_LIMIT_A
● PZD3 in telegrams 901 and 902, output signals
● SLS limit value input
● Value range 1 ... 32767; 32767 ≙ 100% of the 1st SLS level
10.5.2.7 S_SLS_LIMIT_A_ACTIVE: Active SLS limit value
S_SLS_LIMIT_A_ACTIVE
● PZD3 in telegrams 901 and 902, input signals
● Active SLS limit value
Data descriptions
10.5 Process data
Safety Integrated (with SINAMICS S120)
370 Commissioning Manual, 02/2020, A5E46305916B AB
