6.6.14 SS2E
Precondition
● The Safety Integrated commissioning mode (Page 249) is active for the drive to be
configured.
● The drive is configured for operation with an encoder and Extended Functions.
Display commissioning screen "Safe Stop 2 with external stop - SS2E"
MENU SELECT > Commissioning > Menu forward key > Safety > Functions > Menu forward
key > SS2E
Figure 6-32 Safe Stop 2 with external stop - SS2E
Commissioning and configuring
6.6 Configuring safety functions integrated in the drive
Safety Integrated (with SINAMICS S120)
298 Commissioning Manual, 02/2020, A5E46305916B AB
