Byte Bit Meaning Remarks
2 0 ... 2 Reserved – –
3 SLP active position range
1)
1 SLP area 2 (SLP2) active
0 SLP area 1 (SLP1) active
- The status signal "SLP active position range" al‐
ways corresponds to the diagnostic signal "SLP
active position range" (r9722.19).
4, 5 Reserved - -
6 Safe position valid 1 Safe position valid
0 Safe position invalid
7 Safely referenced 1 Safe position is applicable as "safely referenced"
0 Safe position is not applicable as "safely refer‐
enced"
1)
Signals not relevant for Extended Functions: Must not be evaluated.
Data descriptions
10.5 Process data
Safety Integrated (with SINAMICS S120)
Commissioning Manual, 02/2020, A5E46305916B AB 369
