Softkey Purpose
Drive + The settings are specific to a certain drive. Switch to the corresponding drive using the appro‐
priate softkey before configuring.
Drive -
Select a drive
Recommended values Using softkey "Recommended values", you can automatically preassign the values of the par‐
ticular startup screen form.
For example, in the startup screen form "Telegram configuration", the telegram types from the
configuration belong to the settings that can be assigned as default.
Check the individual suggested values.
Making the settings
Table 6-8 SIC/SCC telegram settings (Settings - telegram configuration)
Setting Meaning
Enable SIC/SCC Enables/inhibits the evaluation of the Safety Info Channel/Safety Control
Channel (SIC/SCC).
This option is automatically activated when setting the function scope
(Page 251).
SIC/SCC module number Sets the SIC/SCC module number.
Telegram configuration Sets the telegram type for the Safety Info Channel (SIC)/Safety Control
Channel (SCC).
Table 6-9 PROFIsafe telegram settings (Settings - telegram configuration)
Setting Meaning
PROFIsafe address Sets the PROFIsafe address for the Control Unit.
Telegram configuration Sets the PROFIsafe telegram type.
Safety parameter assign‐
ment
Sets the PROFIsafe telegram type for the Control Unit.
Stop response for PROFI‐
safe communication failure
Setting the stop response in case of failure of the PROFIsafe communi‐
cation
Commissioning and configuring
6.5 Configuring NC and drive-specific safety settings
Safety Integrated (with SINAMICS S120)
Commissioning Manual, 02/2020, A5E46305916B AB 265
